High Temperature Laboratory Vacuum Furnace High Temperature Muffle Furnace Electric Nitrogen Argon Burnout Oven Lab Mini Tube Stove, Max. 1100℃, AC110V Single-Phase

Product Parameters Voltage: AC220V, single-phase Power: 2kW Working tube size: Φ1.57*19.6" (Φ40×500mm) (Optional: Φ50mm/Φ60mm) Working tube: High-temperature transparent SiO₂ Heating element: Molybdenum-doped alloy wire Rated temperature: ≤1100℃ (2012℉) Maximum temperature: 1100℃ (2012℉) (not recommended for continuous long term use at this temperature) Effective constant temperature length: 4.7" (120mm) Temperature control instrument: 30 segment AI programmable PID control Temperature control accuracy: ±1℃ Instrument display: 0.1℃ (minimum display resolution 0.0℃) Temperature field uniformity: ±3℃ Temperature measuring element: K-type thermocouple Temperature control method: Programmable intelligent automatic temperature controller Heating rate: 0-15℃/min Shell material: Laser-processed iron plate baking paint Furnace chamber: Alumina polycrystalline insulation material Maximum positive pressure: <0.02 MPa Sealing method: Stainless steel compression seal flange Atmosphere: Applicable gases: Nitrogen, argon and other inert gases Machine size: 29.5*13.0*15.1" (75×33×38.5cm) Package size: 23.6*15.7*16.5" (60×40×42cm) Net weight / Gross weight: 55.1lbs(25kg) / 61.7lbs(28kg) Please note that: Machine comes with a US plug, but we sincerely recommend user to hook up the machine with circuit breaker for security concerns

• Programmable Temperature Controller: The atmosphere furnace control panel integrates multiple functions, including temperature controller, time setting, start, stop and power switch, it's also equipped with an intelligent LCD screen, to clearly display data, besides, the furnace adopts a programmable digital temperature control system, which enables fully automated operation and ensures data accuracy
• Precise Temperature Control: The high temperature lab vacuum furnace adopts an advanced PID intelligent temperature control system, with high precision, the temperature control is within ±1℃, meeting the strict experimental requirements, there is also a pressure gauge with shock-proof design and high precision, to enable clear observation of the pressure changes in the furnace
• Uniform Temperature Distribution: The split-hinged furnace chamber enables 90° horizontal swing opening, for easy sample access and cleaning, the molybdenum-doped alloy heating element can maintain uniform temperature distribution even after opening,moreover, thw high-vacuum valve with 304 stainless steel body can be used with quick-release flanges for rapid installation and airtight sealing, which greatly ensures the accuracy of the test results
• High-Temperature Resistant Material: The maximum temperature of the furnace can reach 1100℃ (2012℉), the chamber is constructed with premium refractory materials, capable of withstanding extreme working temperatures while ensuring excellent thermal stability and durability, besides, the furnace has heat dissipation holes, to discharge the excess heat generated during operation, preventing overheating and protecting the machine (It is not recommended to use at 1100℃ for an extended period)
• Wide Application Scope: With precise temperature control and uniform temperture distribution, this lab mini tube heating oven is widely used in universities, research institutes, and industrial enterprises for high-temperature atmosphere sintering, gas reduction, CVD experiments, vacuum annealing, and more
